Camphor Synthetic

Product Name:

Camphor synthetic

CAS:

76-22-2

MF:

C10H16O

MW:

152.23

EINECS:

200-945-0

Mol File:

76-22-2.mol

Melting point

175-177 °C(lit.)

Boiling point

204 °C(lit.)

density

0.992

vapor density

5.2 (vs air)

vapor pressure

4 mm Hg ( 70 °C)

FEMA

4513 | dl-CAMPHOR

refractive index

1.5462 (estimate)

Fp

148 °F

storage temp.

Store below +30°C.

solubility

Soluble in acetone, ethanol, diethylether, chloroform and acetic acid.

form

neat

explosive limit

0.6-4.5%(V)

optical activity

[α]20/D +0.15 to -0.15°, c = 10% in ethanol

Water Solubility

0.12 g/100 mL (25 ºC)

JECFA Number

2199

Merck

14,1732

BRN

1907611

Henry's Law Constant

(x 10-5 atm?m3/mol): 3.00 at 20 °C (approximate - calculated from water solubility and vapor pressure)

Exposure limits

TLV-TWA 12 mg/m3 (2 ppm), STEL 18 mg/m3 (3 ppm) (ACGIH); IDLH 200 mg/m3 (NIOSH). .

Stability:

Stable. Combustible. Incompatible with strong oxidizing agents, metallic salts, combustible materials, organics.

InChIKey

DSSYKIVIOFKYAU-MHPPCMCBSA-N

CAS DataBase Reference

76-22-2(CAS DataBase Reference)

NIST Chemistry Reference

Camphor(76-22-2)

EPA Substance Registry System

Camphor (76-22-2)

Hazard Codes

F,Xn,Xi

Risk Statements

11-22-36/37/38-20/21/22

Safety Statements

16-26-37/39

RIDADR

UN 2717 4.1/PG 3

WGK Germany

1

RTECS

EX1225000

Autoignition Temperature

870 °F

TSCA

Yes

HazardClass

4.1

PackingGroup

III

HS Code

29142910

Hazardous Substances Data

76-22-2(Hazardous Substances Data)

Toxicity

LD50 orally in mice: 1.3 g/kg (PB293505)

Chemical Properties

Camphor is a colorless glassy solid. Penetrating, characteristic odor.

Physical properties

Colorless to white, flammable granules, crystals or waxy semi-solid with a strong, penetrating, fragrant or aromatic odor. Odor threshold concentration is 0.27 ppm (quoted, Amoore and Hautala, 1983).

Uses

dl-Camphor is used as a plasticizer for celluloseesters and ethers; in the manufacture ofplastics and cymene; in cosmetics, lacquers,medicine, explosives, and pyrotechnics; andas a moth repellent.

Definition

A ketone occurring naturally in the wood of the cam- phor tree (Cinnamomum camphora).

Raw materials

Sodium hydroxide-->Acetic acid glacial-->Sodium carbonate-->Xylene-->Cupric sulfate-->Calcium hydroxide -->Turpentine oil-->Metatitanic acid-->DL-Isoborneol-->C. I. Pigment Blue 30 (77420)-->CRESYL VIOLET ACETATE-->White camphor oil

Preparation Products

Cinene-->Sodium (+)-10-camphorsulfonate-->D-(+)-Camphoric acid
